规格
牙距
h
m
s
e
max.
min.
min
mm
M5
0.8
6.3
6
3.52
8
7.78
8.79
M6
1
7.7
3.92
10
9.78
11.05
M7
8.5
8.2
9.91
11
10.73
12.12
M8
1.25
9.5
9.14
5.15
13
12.73
14.38
M10
1.5
11.5
11.14
6.49
17
16.73
18.9
M12
1.75
14
13.64
9.3
19
18.67
21.1
M14
2
16
15.3
9.68
22
21.67
24.49
M16
18
17.3
11.28
24
23.67
26.75
M18
2.5
20
19.16
12.08
27
26.16
29.56
M20
20.7
13.52
30
29.16
32.95
M22
25
23.7
14.48
32
31
35.03
M24
3
28
26.7
16.16
36
35
39.55
M30
3.5
32.6
30.1
19.44
46
45
50.85
M36
4
38.9
36.4
23.52
55
53.8
60.79
